Specification

Minimum working weight, flange mounted  *1499 kg1110 lb
Width1829 mm72.00 in
Height700 mm27.56 in
Pressure line size, min. inner diameter16 mm0.63 in
Return line size, min. inner diameter16 mm0.63 in
Skid steer, robot weight, range  *21.8 - 5.5 t4000 - 12000 lb
Impulse force 8000 lb
Operating frequency2000 rpm
Hydraulic flow options18 gal/min
Compaction plate dimensions18 x 84 in
Mounting bracket typeSSU
Carrier weight4000 lb (Minimum)
*1   Includes average mounting bracket and standard wear parts
*2   Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.

Specifications are subject to change without notice (Wednesday, August 23, 2023)
