Specification

Minimum working weight, flange mounted  *11120 lb
Height648 mm25.51 in
Miniexcavator, tractor backhoe weight, Range  *24 - 11 t9000 - 30000 lb
Carrier weight, range  *26 - 14 t14000 - 30000 lb
Impulse force 8000 lb
Operating frequency2000 rpm
Hydraulic flow options12/18/21 gal/min
Compaction plate dimensions24 x 37 in
Mounting bracket typeBR/SR
*1   Includes average mounting bracket and standard wear parts
*2   Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.

Specifications are subject to change without notice (Wednesday, August 23, 2023)
