Specification

Minimum working weight, flange mounted  *1750 lb
Height546 mm21.5 in
Carrier weight, range  *23.6 - 9 t8000 - 20000 lb
Impulse force 6400 lb
Operating frequency2000 rpm
Hydraulic flow options6/9/14/18 gal/min
Compaction plate dimensions18 x 35 in
Mounting bracket typeXR/BR
*1   Includes average mounting bracket and standard wear parts
*2   Check carrier allowed attachment weight from carrier manufacturer. Check application requirements.

Specifications are subject to change without notice (Wednesday, August 23, 2023)
